Mounted X Type Tandem Disc Harrow Product Manuals

WARNINGS REGARDING HUMAN HEALTH AND ENVIRONMENTAL HAZARDS DURING USE

When you attach your machine to the tractor and go to traffic, follow traffic rules, especially lighting and necessary protection mechanisms, and take safety precautions. Comply fully with safe handling and Accident Protection instructions.

Lighting equipment (stop lamps,cat eyes, etc.) that allows tractors to be seen by other drivers while watching on the highway should always be clean and operational.

During breaks, the tractor must be passed through a general control (rubber air and malfunctions, loose nuts, safety pin, traffic lights, etc.).

For the machines that are outside the tractor, attach a sign flag.

Use appropriate work clothing. Do not use loose clothing. They can be covered by rotating and moving machine parts.

If you are going to use the machine for the first time, read all instructions carefully. In case of doubt, contact the manufacturer/importer company. It is forbidden for third parties who are unauthorized and not trained to use and maintain the machine. Do not operate in poor lighting conditions.

If it is not connected to the tractor, it should not be parked on a inclined surface and should be prevented from moving safely in case it is not connected to the tractor.

Do not expose the machine to excessive force during use and maintenance.

When transferring your machine to another location, be sure to remove it from the points of removal specified on the machine.

In order to connect the machine and tractor, the tractor must be brought closer to the machine. The machine should not be stepped on and not to come in front due to the danger of tripping in case of movement of the machine on top of the machine and in case of movement. Regularly check protective cover and parts against wear and tear.

Only connect the specified type of tractors according to the instructions. or change it before using bent parts.

When the hydraulic handle is lowered, be careful when the hydraulic handle is lowered because it may be subject to impact hazard if it is located in the danger zone. Do not touch the moving and rotating parts in any way.

Wait until they stop completely before touching the machine elements.

Do not put weight on the machine while it is operating and while it is stationary, do not remove human beings from the danger of puncturing or deflecting, and do not put your hand into it. When machine is not connected to the tractor should be placed in a balanced place. When the hydraulic handle is lowered, be careful when the hydraulic handle is lowered because it may be subject to impact hazard if it is located in the danger zone.

It should not be entered under the casing, bunker with raised hydraulic equipment.

After connection is made on the hydraulic set models, it should be checked whether there is leakage in the hydraulic hoses and connection points.When the hydraulic connection is made, the danger zone should be protected and pressure should be adjusted and controlled visually. Make sure that the person using the tractor to which your machine is mounted is a licensed (F) and experienced driver.

The exhaust gas is toxic. Therefore the tractor should not be operated in unsuitable and indoors.

The clutch should be thrown-in smoothly and the tractor should be moved. Sudden and hard starts can cause dangerous springs and rearing up, especially when going uphill or taking loads.

When driving downhill, the gear must not be released.

Never ride on the tractor while it is moving.

When going to the highway, make sure that the brake pedals are connected to each other (with the brake latch attached). Otherwise, the tractor is thrown dangerously during braking.

Other than the person using the tractor, one or a few passengers should not be carried when the tractor is in motion unless the tractor is equipped with sitting place or places.

When necessary, the tractor front or rear weights should be installed or tyres should be filled with water.

The tractor should always be used with its own safety frame mounted on it. The safety frame must be checked from time to time to ensure that its connections are complete, not broken or defective.

In very hot weather the fuel tank should not be filled fully. The volume of the fuel can be increased by heat. Any leak that occurs should be immediately wiped and cleaned.

The tractor should not be tried to operate and maneuver before sitting in the driver’s seat.

During the field trip and return, stretch the side chains of the tractor hydraulic arms. The three-point connector must be attached to the safety pins. Hydraulics must be locked.The connection shaft must be removed.

Please note that some functions of the tractor (brake distance, steering wheel, center of gravity, etc.) shall change.

Especially in mounted machines, going to the field, turn corners and bumps should be entered very slowly.

The tractor front selection lever should be in “position control”.

Check tire pressures before getting off and during breaks.

Slow and careful action should be taken when pulling heavy loads. Only the towing hook must be used for the towing operation. If there is no proper clamping scheme, it should not be attempted to use hydraulic lifting, middle suspension and side-rowing arms. Otherwise, it may cause a rearing up.

Connect your machine to the tractor in the appropriate category specified in the instructions for use with an appropriate pull power and hydraulic lifting scheme. The control device must be in position “0” before connecting and disconnecting on mounted type machines.

Your machine and tractor should have the same category as the three-point mounting scheme. Before connecting your machine to the tractor, pull the tractor’s handbrake, and shift the gear to neutral. Be very careful when connecting and disconnecting the machine to the tractor. When connecting the machine to the tractor, there must be no one between the machine and the tractor against the danger of being crushed, pinched, cut and broken.

Start working after taking all safety precautions on your machine and tractor. If your tractor is working, never leave the driver’s quarters.

Be careful of the danger of tipping off when working on inclined terrain.

Precautions should be taken to prevent hazards arising from the change of the center of gravity during loading.

Do not go back during work.

Before you leave the tractor, lower the hydraulic machine. After turning off the engine, pull out the parking brake. Get the ignition key.

Make adjustments to your machine only when the tractor engine is switched off and the wheels are on a wedge. Before starting maintenance, adjustment or repair, take the tractor ‘s ignition key with you. Ensure that the work turn is completely lowered to the ground before leaving the equipment attached to the rear of the tractor.

If possible, the tractor should be parked in a flat place and plug it into one of the gears and the handbrake must be pulled in this case. If it is to be parked on a slope, it should be mounted on the slope up and down first gear, and in both cases the handbrake should be pulled. Especially if the tractor is connected to the trailer, to be more secure wheels should be put a wedge.

Before starting the tractor and machine, make sure that there are no other persons, especially children and pets around the machine, and take the necessary precautions to ensure that you can see the environment easily.

Obstacles such as tree roots with should be disposed of by obstructing land barriers by paying attention to the colths, nylon and similar waste materials. It should not be used in very stony fields. Do not approach to the machine during operation, do not approach anyone.

The correct plowing should be made against the danger of erosion.
